Overview - Belt Pulley, DENSO A/C Compressor
WARNING: This page is about a different variant/trim than selected.
- Bolts
- 4.5 Nm
- Quantity: 3
- Closure Cap
- Nut
- 25 Nm
- Drive Plate
- With overload protection; is activated when the torque is too great (for example, if the A/C compressor runs with resistance) and the belt pulley runs freely without driving the A/C compressor.
- Circlip
- Replace
- Install on the proper side - the flat side faces the A/C compressor
- Belt Pulley
- There are different versions. Refer to the Parts Information.
- Is sensitive to impact, be careful when handling
- Removing and Installing. Refer to BELT PULLEY, REMOVING AND INSTALLING, DENSO A/C COMPRESSOR .
- A/C Compressor
- Clean the A/C compressor input shaft before installing the belt pulley
