Rear Lid, Adjusting: Notes
Special tools and workshop equipment required
- Gauge - Gap Adjustment:3371
Gap Dimensions
 Courtesy of AUDI OF AMERICA, LLC
|
The gap dimensions can be checked with the :3371
.
- Dimension -A- = 4.5 mm
- Dimension -B- = 5.5 mm
- Dimension -C- = 2.3 mm
- Dimension -D- = 2.5 mm
- Dimension -E- = 5.0 mm
- Dimension -F- = 5.3 mm
