Left Rear Central Locking Lock Unit, Left Rear Child Safety Lock Contact Switch, Left Rear Door Control Module, Left Rear Child Safety Lock Motor

Courtesy of AUDI OF AMERICA, LLC

F10  Left rear door contact switch

F132  Left rear central locking system actuator

F222  Left rear central locking lock unit

F344  Left rear child safety lock contact switch

J388  Left rear door control module

T6av  6-pin connector, black

T10aj  10-pin connector, black

T20e  20-pin connector, black

V115  Left rear central locking system motor

V142  Left rear child safety lock motor

V163  Left rear central locking -SAFE- motor

(B397) Comfort system CAN bus high connection 1 (in main wiring harness)

(B406) Comfort system CAN bus low connection 1 (in main wiring harness)

*  Only for vehicles without child safety lock

*2  Only for vehicles with child safety lock

*3  Through October 2015
