Seat Pan Cover And Cushion, Removing And Installing, Sport Seat/Super-Sport Seat: Removing

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2015 Audi S7, 2015 Audi RS 7, 2015 Audi A7 Quattro, 2014 Audi S7, and 2014 Audi RS 7. However, it is still accessible from the selected car via links, so may be relevant.

WARNING:

Follow all Safety Precautions when working with pyrotechnic components. Refer to PYROTECHNIC COMPONENTS SAFETY PRECAUTIONS .
Before handling pyrotechnic components (for example, disconnecting the connector), the person handling it must "discharge static electricity". This can be done by touching the door striker, for example.

-- Remove the front seat. Refer to FRONT SEAT, REMOVING AND INSTALLING .

-- Fasten the front seat on the Engine/Transmission Holder - Seat Repair FixtureVAS6136. Refer to FRONT SEAT, MOUNTING ON FIXTURE FOR SEAT REPAIR .

-- Remove the backrest. Refer to FRONT BACKREST, REMOVING AND INSTALLING, STANDARD SEAT/SPORT SEAT/SUPER SPORT SEAT .

-- Front passenger seat with LATCH child seat anchorage: Remove the LATCH child seat anchorage. Refer to FRONT CHILD SEAT ANCHOR, REMOVING AND INSTALLING .

-- Versions with a storage compartment: Remove the storage compartment. Refer to STORAGE COMPARTMENT, REMOVING AND INSTALLING .

-- Remove the bracket for the sill-side trim:

For the manual sport seat, refer to SEAT SIDE TRIM ON SILL PANEL SIDE, REMOVING AND INSTALLING, FRONT SEAT (MANUAL) .
For the power sport seat/super sport seat, refer to SEAT SIDE TRIM ON SILL PANEL SIDE, REMOVING AND INSTALLING, FRONT SEAT (POWER) .

-- Disconnect and free up the connectors.

-- Pull the seat depth adjuster all the way out.

Fig 1: Identifying Seat Depth Adjuster

Courtesy of AUDI OF AMERICA, LLC

-- Unclip the tabs -2-.

-- Move the support with the seat cushion and seat cover -1- for the seat depth adjuster as far as possible upward -arrow- so that the tab remains unlocked.

-- Remove the support -2- with the seat cushion and seat cover for the seat depth adjuster upward and toward the front.

Fig 2: Laying Support With Seat Cushion And Seat Cover On Front Seat

Courtesy of AUDI OF AMERICA, LLC

NOTE:

The illustration does not show the seat pan lower frame.

-- Unclip the cover retaining strips -1, 3 and 4- and rear cushion.

-- To do this, unclip the retaining channels -1- and -2- in the direction of the -arrow- out from the tabs -3-.

Fig 3: Unclipping Retaining Channels Out From Tabs

Courtesy of AUDI OF AMERICA, LLC

NOTE:

Proceed very carefully when removing and installing because it is relatively easy to damage the tabs.

Front Passenger Seat - country-specific with Passenger Occupant Detection System for Front Passenger Airbag Deactivating:

Fig 4: Disengaging Control Module -2- From Bracket -Arrow- And Free Up Control Module And Wire

Courtesy of AUDI OF AMERICA, LLC

CAUTION:

Never disconnect the connector -4- from the Passenger Occupant Detection System Control Module -J706-.

-- Disconnect the connector -3- from the control module.

-- Remove the bolt -1-.

-- Disengage the control module -2- from the bracket -arrow- and free up the control module and wire.

Continuation for Driver Seat and Front Passenger Seat:

Fig 5: Disengaging Hooks -1- And -4- From Lower Seat Frame -2-

Courtesy of AUDI OF AMERICA, LLC

-- Disengage the hooks -1- and -4- from the lower seat frame -2-.

-- Disconnect and free up the connectors.

-- Detach the molding -3- of the seat cover -5- in the rear area using the Backrest Panel Tool3370.

-- Detach the molding -1 and 2- of the seat cover in the front and side areas using the Backrest Panel Tool3370.

Fig 6: Removing Seat Cover -4- With Seat Cushion From Seat Pan -3-

Courtesy of AUDI OF AMERICA, LLC

-- Remove the seat cover -4- with the seat cushion from the seat pan -3-. If necessary, free up the wiring harness for the seat heating and passenger occupant detection system.

NOTE:

The seat depth adjuster support (plastic) remains on the seat cushion.
