Insulation, Removing And Installing

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2015 Audi S7, 2015 Audi RS 7, 2015 Audi A7 Quattro, 2014 Audi S7, and 2014 Audi RS 7. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Clip, Hold Panel And Door

Courtesy of AUDI OF AMERICA, LLC

Clip
Hold Panel
- Installation:
  -- Slide the lining over the tabs on the rear edge into the holes provided on the inner panel.

  -- Slide the tabs on the front edge and the sides into place.

  -- The clips must engage audibly when pressing in.

  -- Press the clip in.
Door
Clip
