Driver Door Control Module -J386- AND Front Passenger Door Control Module -J387-, REMOVING AND INSTALLING

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2015 Audi S7, 2015 Audi RS 7, 2015 Audi A7 Quattro, 2014 Audi S7, and 2014 Audi RS 7. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Driver Door Control Module -J386- And Front Passenger Door Control Module -J387-

Courtesy of AUDI OF AMERICA, LLC

-- Remove the door trim panel. .

-- Open the release and the disconnect the connectors -1- and -2-.

-- Disconnect the connector -3-.

-- Disconnect the connector -4- on the door control module.

-- Press the retaining detent -5- in direction of -arrow- and disengage the door control module -6- on the door shell.

Installing

-- Installation in reverse order of removal making sure the retainer locks into the inner door panel.
