Floor Panel For Rear Bench Seat Mounting Grommets And Wire Frame, Checking And Aligning

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2015 Audi S7, 2015 Audi RS 7, 2015 Audi A7 Quattro, 2014 Audi S7, and 2014 Audi RS 7. However, it is still accessible from the selected car via links, so may be relevant.

Check and Adjust the Floor Panel

Fig 1: Check Floor Panel For Deformation And Adjust If Necessary

Courtesy of AUDI OF AMERICA, LLC

-- Check body openings -1- for deformations.

-- In the case of deformation, readjust the panel with a plastic hammer.

NOTE:

Remaining minor deformation is permissible.

Checking and Adjusting the Rear Bench Seat Wire Frame

Fig 2: Rear Bench Seat Wire Frame

Courtesy of AUDI OF AMERICA, LLC

-- Check if the wire frame is aligned in the marked area -arrows- before installing the rear bench seat.

-- If the wire frame is bent, bend it back far enough until it is realigned -arrow-.
