Outer Rear Three-Point Seat Belt, Removing And Installing: Removing

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2015 Audi S7, 2015 Audi RS 7, 2015 Audi A7 Quattro, 2014 Audi S7, and 2014 Audi RS 7. However, it is still accessible from the selected car via links, so may be relevant.

-- Remove the rear belt anchor. Refer to REAR OUTER BELT END FITTING, REMOVING AND INSTALLING .

-- Remove the luggage compartment side trim. Refer to LUGGAGE COMPARTMENT SIDE TRIM PANEL, REMOVING AND INSTALLING .

-- Remove the rear seat belt guides. Refer to OUTER REAR SEAT BELT GUIDE, REMOVING AND INSTALLING .

-- Remove the noise insulation for the automatic belt retractor.

Versions with rear seat belt tensioner igniter:

WARNING:

Follow all Safety Precautions when working with pyrotechnic components. Refer to PYROTECHNIC COMPONENTS SAFETY PRECAUTIONS .
Follow all regulations when disposing of pyrotechnic components. Refer to AIRBAG, BELT TENSIONER AND BATTERY CUT-OUT UNITS, STORING, TRANSPORTING AND DISPOSING .

-- Disconnect the battery ground cable with the ignition turned on. Refer to BATTERY, DISCONNECTING AND CONNECTING .

WARNING:

Before handling pyrotechnic components (for example, disconnecting the connector), the person handling it must "discharge static electricity". This can be done by touching the door striker, for example.

-- Disconnect the connector.

Fig 1: Disconnecting Harness Connector -1-, Connector Lock -2-

Courtesy of AUDI OF AMERICA, LLC

-- Release the connector lock -2- with a small screwdriver -arrow- and disconnect the connector -1-.

Continuation for all vehicles:

Fig 2: Removing Bolt -1- And Three-Point Seat Belt -2-

Courtesy of AUDI OF AMERICA, LLC

-- Remove the bolt -1- and the three-point seat belt -2- from the mount.
