Vehicle Cabin Grounds, Right, Part III

  1. 676 - Ground connection 2 in luggage compartment, left
    • Torque Setting 9 Nm
  2. 50 - Ground Connection (in luggage compartment, left)
    • Torque Setting 9 Nm
G12767441Courtesy of AUDI OF AMERICA, LLC
