Overview - Outer Rear Three-Point Seat Belt
WARNING: This page is about a different variant/trim than selected.
NOTE:
The illustration shows the rear three-point seat belt for the A3.
- Belt GuideCAUTION:
- Do not rotate bolts under any circumstances when removing and installing belt guide. They are set by the manufacturer.
- Replace the entire seat belt guide if damaged.
- Removing and Installing. Refer to REAR SEAT BELT GUIDE, REMOVING AND INSTALLING .
- Insert in the guides on the bracket with the bolt heads and pull forward until the catches engage audibly
- Bolt
- 40 Nm
- Replace the bolt if it was removed because of an accident when the seat belt was buckled.
- Automatic Belt Retractor
- Removing and Installing. Refer to REAR THREE-POINT SEAT BELT, REMOVING AND INSTALLING .
- Bolt
- 40 Nm
- Replace the bolt if it was removed because of an accident when the seat belt was buckled.
- Outer Rear Belt End Fitting
- Removing and Installing. Refer to REAR THREE-POINT SEAT BELT, REMOVING AND INSTALLING .
