Overview - Seat Pan, Seat Angle Adjuster
WARNING: This page is about a different variant/trim than selected.
- Seat Angle Adjustment Handle
- Removing and Installing. Refer to SEAT ANGLE ADJUSTMENT HANDLE, REMOVING AND INSTALLING .
- Bolt
- 9 Nm
- Quantity: 2
- Seat Angle Adjuster
- Removing and Installing. Refer to SEAT ANGLE ADJUSTER, REMOVING AND INSTALLING .
- Seat Pan
- Bolt
- 6 Nm CAUTION:
The bolt has a left-hand thread.
- Self-locking
- Replace after removing.
- Clean the threaded hole for the bolt with a thread tap, for example
- 6 Nm
- Bolt
- 6.5 Nm
- Self-locking
- Replace after removing.
- Threaded holes for the bolts must be cleaned, for example, with a thread tap
