Overview - Rear Sill Panel Strip, A3 SPORTBACK/Sedan
WARNING: This page is about a different variant/trim than selected.
- Clip
- Insert in the sill panel
- Grommet
- Install inside the body
- Expanding Clip
- Sill Panel
- Removing and Installing. Refer to SILL PANEL, REMOVING AND INSTALLING .
- Place the sill panel strip in the belt guide and the C-pillar trim.
- Press on until it engages audibly
- Stretch the door seal lip over
- Clip
- Quantity: 3
- Insert in the sill panel
- Remove any remaining clips in the body mounting points using the Omega Clip Tool :T40280 . To install, insert into the sill panel strip.
- Replace damaged or deformed clips
