Overview - Footrest And Carpet
WARNING: This page is about a different variant/trim than selected.
- Footrest
- Removing and Installing. Refer to FOOTREST, REMOVING AND INSTALLING .
- Must engage completely in the bracket
- Nut
- 2 Nm
- Quantity: 3
- Bracket
- For the footrest
- Removing and Installing. Refer to FOOTREST, REMOVING AND INSTALLING .
- Steering Column Trim
- Removing and Installing. Refer to STEERING COLUMN COVER, REMOVING AND INSTALLING .
- Nut/Button
- Nut: 2 Nm
- Quantity: 2
- Button; push until stop
- Carpet
- One piece
- Removing and Installing. Refer to CARPET, REMOVING AND INSTALLING .
