Overview - D-Pillar Trim Panel, Sedan
WARNING: This page is about a different variant/trim than selected.
- D-Pillar Trim Panel
- There are different versions.
- Through 06/26/2017 with expanding cap
- From 07/27/2017 without expanding cap
- Removing and Installing. Refer to D-PILLAR TRIM PANEL, REMOVING AND INSTALLING, SEDAN .
- Insert in the rear shelf and press on it until it engages audibly.
- Spreader clips
- Only versions with expanding caps
- Insert in the trim panel
- Remove any remaining clips in the body mounting points using the Omega Clip Tool :T40280 . To install, insert into the trim panel.
- Replace damaged or deformed clips
- Expanding Cap
- Only versions with expanding caps
- With the "Airbag" symbol
- Carefully unclip
