Crash Bolster, Removing And Installing: Installing
WARNING: This page is about a different variant/trim than selected.
NOTE:
When crash brace is replaced on a vehicle through 11/2012 a felt strip is to be attached to the crash brace.
The reason is to make a smaller distance to the footwell vent.
-- Vehicles with a manual transmission attach the felt strips -2- 7.5 mm apart = dimension -a- to the edge of the crash brace -1-.
Further installation is performed in reverse order of removal, while Noting The Following:
-- Engage the crash bolster -2- on the crossmember -1- -arrow- and fasten.
