Overview - Wheel Bearing Unit
WARNING: This page is about a different variant/trim than selected.
- Dust Cap
- Always replace if removed
- Bolt
- :WHT.005.437 / black = 200 Nm + 180° turn
- :WHT.005.437.A / silver =200 Nm + 90° turn
- Always replace if removed
- Loosening and tightening. Refer to DRIVE AXLE THREADED CONNECTION, LOOSENING AND TIGHTENING
- Before installing, clean the threads in the axle stub with a thread tap.
- Wheel Bearing Unit
- Removing and installing. Refer to WHEEL BEARING UNIT, REMOVING AND INSTALLING, TORSION BEAM AXLE VEHICLES WITH FRONT WHEEL DRIVE .
- The wheel bearing and wheel hub are installed together in a housing
- The wheel bearing unit is maintenance free and has zero play. Adjusting or servicing is not possible!
- Bolt
- 30 Nm + 90°
- Always replace if removed
- Brake Shield
- Removing and installing. Refer to BRAKE SHIELD, REMOVING AND INSTALLING .
- Stub Axle
- Axle Beam
