Overview - Noise Insulation, Standard Equipment
WARNING: This page is about a different variant/trim than selected.
- Bolt
- 2 Nm
- Metal Nut
- Front Noise Insulation
- There are different versions.
- Removing and Installing. Refer to FRONT NOISE INSULATION, REMOVING AND INSTALLING .
- Bolt
- 2 Nm
- Expanding Rivet
- Expanding Rivet
- Quantity: 4
- Rear Noise Insulation
- Equipped on some models
- Removing and Installing. Refer to REAR NOISE INSULATION, REMOVING AND INSTALLING, VERSION 1 .
- Rear Noise Insulation
- Equipped on some models
- Removing and Installing. Refer to REAR NOISE INSULATION, REMOVING AND INSTALLING, VERSION 2 .
- Bolt
- 6 Nm
- Quantity: 3
- Replace after removing.
- M8x20
- Bolt
- 2 Nm
- Quantity: 6
