Overview - Headlamp, Headlamp Mount
WARNING: This page is about a different variant/trim than selected.
- Lock Carrier
- For mounting the headlamp
- Mount
- For headlamp
- Removing and installing. Refer to HEADLAMP MOUNT, REMOVING AND INSTALLING .
- Bolt
- 4.5 Nm
- Mount
- For the bumper cover
- To secure the headlamp
- Bolt
- Tightening Specification. Refer to OVERVIEW - FENDER /FENDER, REMOVING AND INSTALLING
