Side Air Intake Trim, Removing And Installing, RS3 SPORTBACK: Removing

WARNING: This page is about a different variant/trim than selected.

-- Remove the front bumper cover. Refer to BUMPER COVER, REMOVING AND INSTALLING .

-- Free up the washer fluid hose.

-- Release the catches -arrows- and remove the trim -2- toward the rear off of the bumper cover.

GWWA63-11056Courtesy of AUDI OF AMERICA, LLC
