Battery In Engine Compartment, Removing And Installing: Installing
Install in the reverse order of removal. Note the following:
Only maintenance-free batteries conforming to standards "TL82506" (from 12/1997) and "VW75073" (from 08/2001) may be installed.
Batteries from the Audi Parts Program have a bottom strip-adapter for adapting to different grip channels. For information on how to use the base strip adapter, if applicable, see the battery operating instructions.
-- Insert the battery into the battery tray -1- so that the battery base strip touches the rear and side stop -arrows-.
- It should no longer be possible to move the battery.
-- Install the battery bracket -2-.
- The tab -arrow- on the battery mounting bracket must fit into the opening on the battery clamping strip.
-- Tighten the bolt -1- for the battery bracket.
-- Turn off the ignition and all electrical consumers, and connect the battery in the following sequence:
-- First connect the positive battery cable terminal -3- to the battery positive pole "+" by hand and tighten the nut -4-.
-- Market-specific: Disconnect the connector -2- from the Battery Monitoring Control Module -J367- -3-.
-- Connect the battery ground cable terminal to the battery negative pole "-" by hand and tighten the nut -1-.
-- Reconnect the connector to the Battery Monitoring Control Module -J367-.
-- Make sure the battery is secure after installation.
-- If the battery was replaced, then the new battery must be adapted.
