Accelerator Pedal Position Sensors -G79- / -G185-, Removing And Installing: Removing
WARNING: This page is about a different car, the 2015 Audi A3. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the steering column cover -2-. Refer to STEERING COLUMN, REMOVING AND INSTALLING .
-- Disconnect the connector -2- from the accelerator pedal module, to do so press the release upward.
Fig 1: Accelerator Pedal Position Sensor -G79- / Accelerator Pedal Position Sensor 2 -G185- Component Location
-- Remove the bolt -1-.
-- Remove the accelerator pedal module -3- from the mount.
