Overview - Hood
WARNING: This page is about a different variant/trim than selected.
- Hood
- A second technician is needed to support and hold the hood during removal and installation.
- Removing:
-- Remove the gas-filled strut from the hood. Refer to GAS-FILLED STRUT, REMOVING AND INSTALLING .
-- Remove the nuts -4- from the upper hood hinge.
-- Remove the hood.
- Install in reverse order of removal.
- Adjusting:
-- Center the hood between the fenders.
-- Adjust the height of the hood over the lower part of the lid latch.
-- Adjust the gap between the hood and the fenders using the stop buffers. Refer to Figure.
- Bolts
- 21 Nm
- Lid Hinge
- For Removal And Installation, The Hood Must Be Removed Or Supported Securely.
- Removing:
-- Remove the gas-filled strut. Refer to GAS-FILLED STRUT, REMOVING AND INSTALLING .
-- Remove the bolts -2- and nuts -4-.
- Install In Reverse Order Of Removal.
- Nuts
- 21 Nm
- Gas-Filled Strut
- Removing and installing. Refer to GAS-FILLED STRUT, REMOVING AND INSTALLING .
- Install With Tube End Of Strut At Body.
- Ball Pin
- 21 Nm
- Nuts
- 8 Nm
- Hook
