Overview - Rear Outer Three-Point Seat Belt
WARNING: This page is about a different variant/trim than selected.
- Bolts
- Do not change the bolt position when removing and installing, it is set by the manufacturer.
- Belt Guide
- Replace the entire belt guide if damaged.
- Removing and installing. Refer to REAR SEAT BELT GUIDE, REMOVING AND INSTALLING .
- Nut
- Bolt
- 45 Nm
- If it was removed because of an accident, replace the bolt
- Automatic Belt Retractor
- Depending on the market version with Driver Side Rear Seat Belt Tensioner Igniter -N196-
- Depending on the market version with Passenger Side Rear Seat Belt Tensioner Igniter -N197-
- Removing and installing. Refer to REAR THREE-POINT SEAT BELT, REMOVING AND INSTALLING .
- Noise Insulation
- For the automatic belt retractor
- Belt Webbing
- Bolt
- 45 Nm
- If it was removed because of an accident, replace the bolt
- Belt End Fitting
- Removing and installing. Refer to REAR OUTER BELT END FITTING, REMOVING AND INSTALLING .
