Rear Seat Backrest, 2/3 Right without a Pass-Through

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2018 Audi S6, 2018 Audi A6 Quattro, 2018 Audi A6, 2017 Audi S6, and 2017 Audi A6 Quattro. However, it is still accessible from the selected car via links, so may be relevant.

Courtesy of AUDI OF AMERICA, LLC

-- Vehicles without a storage compartment: remove the rear center armrest trim. Refer to CENTER ARMREST BRACKET/HINGE, REMOVING AND INSTALLING, DIVIDED REAR SEAT BACKREST .

-- Vehicles with a storage compartment: remove the rear storage compartment inside the rear center armrest. Refer to REAR SEAT BACKREST CENTER STORAGE COMPARTMENT, REMOVING AND INSTALLING .

-- Version with 3-seat rear bench seat: Remove the rear center belt guide. Refer to REAR SEAT BELT GUIDE IN REAR SEAT BACKREST, REMOVING AND INSTALLING .

-- Detach the protective strip -2- for the backrest cover inside the opening for the rear center armrest from the retaining straps -1-.

-- Starting at the locking mechanism, pry off the clamping strip -2- for the backrest cover using a screwdriver all around the backrest frame -3- -arrow-.

Courtesy of AUDI OF AMERICA, LLC

-- Vehicles with seat heating: free up the seat heating connector

-- Remove the rear headrest guides. Refer to HEADREST GUIDE, REMOVING AND INSTALLING, STANDARD/SPORT SEAT/SUPER SPORT SEAT .

-- Remove the backrest cover -1- and backrest cushion from the backrest frame.

Rear Seat Backrest, 2/3 Right with A Pass-Through

Courtesy of AUDI OF AMERICA, LLC

-- Remove the rear center armrest and the pass-through door. Refer to PASS-THROUGH COVER, REMOVING AND INSTALLING .

-- Remove the pass-through cover frame. Refer to PASS-THROUGH COVER FRAME, REMOVING AND INSTALLING .

-- Starting at the locking mechanism, pry off the clamping strip -2- for the backrest cover using a screwdriver all around the backrest frame -3- -arrow-.

-- Pry off the clamping strip -4- for the backrest cover with a screwdriver from the opening for the pass-through.

-- Vehicles with seat heating: free up the seat heating connector

-- Remove the rear headrest guides. Refer to HEADREST GUIDE, REMOVING AND INSTALLING, STANDARD/SPORT SEAT/SUPER SPORT SEAT .

-- Remove the backrest cover -1- and backrest cushion from the backrest frame.
