Overview - Rear Side Airbag, Market-Specific

WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2018 Audi S6, 2018 Audi A6 Quattro, 2018 Audi A6, 2017 Audi S6, and 2017 Audi A6 Quattro. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Rear Side Airbag, Market-Specific Exploded View

Courtesy of AUDI OF AMERICA, LLC

Bolt
- 10 Nm
- Quantity: 2
- Replace
Rear Side Airbag
- Driver side: with Driver Side Rear Thorax Airbag Igniter -N201-
- Passenger side: with Passenger Side Rear Thorax Airbag Igniter -N202-
  WARNING:
  Follow all Safety Precautions when working with pyrotechnic components. Refer to SAFETY PRECAUTIONS WHEN WORKING WITH PYROTECHNIC COMPONENTS .
- Removing and installing. Refer to REAR SIDE AIRBAG WITH IGNITER, REMOVING AND INSTALLING, MARKET-SPECIFIC .
Rear Seat Backrest
- Removing and installing. Refer to REAR SEAT BACKREST, REMOVING AND INSTALLING, MULTI-CONTOUR SEAT .
