Impact Guard, Removing And Installing

WARNING: This page does not describe the selected car, but rather 13 other vehicles, including the 2017 Audi SQ5, 2017 Audi Q5, 2016 Audi SQ5, 2016 Audi Q5, and 2015 Audi SQ5. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:

The impact guard is also equipped with double-sided adhesive tape.

Fig 1: Identifying Hood Impact Guard
GWWA55-10502Courtesy of AUDI OF AMERICA, LLC
  1. Door
  2. Impact Guard
    • To remove, remove the clip from the hood and then remove the impact guard.
  3. Clip
