Impact Absorber, Removing And Installing
WARNING: This page does not describe the selected car, but rather 13 other vehicles, including the 2017 Audi SQ5, 2017 Audi Q5, 2016 Audi SQ5, 2016 Audi Q5, and 2015 Audi SQ5. However, it is still accessible from the selected car via links, so may be relevant.
- Impact Member
- For vehicles without a trailer hitch
-- Remove the rear bumper cover. Refer to BUMPER COVER, REMOVING AND INSTALLING .
-- Remove the bolts -1- while counterholding the nuts -3-.
-- Remove the impact member.
- For vehicles without a trailer hitch
- Bolt
- 15 Nm
- Nut
- 15 Nm
- Left Impact Member Mount
