RS 4 Emblem, Removing and Installing

WARNING: This page does not describe the selected car, but rather 18 other vehicles, including the 2016 Audi S4, 2016 Audi A4 Quattro, 2016 Audi A4, 2015 Audi S4, and 2015 Audi A4 Quattro. However, it is still accessible from the selected car via links, so may be relevant.

Removing

-- Remove the lock carrier cover. Refer to LOCK CARRIER COVER, REMOVING AND INSTALLING .

-- Release the tabs in direction of -A arrows-.

-- Remove the quattro name badge -1- on the vehicle exterior from the radiator grille in direction of -arrow B-.

Fig 1: Removing/Installing RS 4 Emblem

Courtesy of AUDI OF AMERICA, LLC

Installing

Install in reverse order of removal. Note the following:

-- Position the quattro name badge on the radiator grille and press it on until it clicks into place.

-- Install the lock carrier cover. Refer to LOCK CARRIER COVER, REMOVING AND INSTALLING .
