Sun Shade Assembly Overview
WARNING: This page does not describe the selected car, but rather 18 other vehicles, including the 2016 Audi S4, 2016 Audi A4 Quattro, 2016 Audi A4, 2015 Audi S4, and 2015 Audi A4 Quattro. However, it is still accessible from the selected car via links, so may be relevant.
- Bolt
- 2 Nm
- Quantity: 4
- Front of the Rear Shelf
- Equipment levels
- Removing and installing. Refer to REAR SHELF, REMOVING AND INSTALLING .
- Sun Shade
- Equipment levels
- Removing and installing. Refer to SUN SHADE, REMOVING AND INSTALLING .
- Bolt
- 2.3 Nm
- Quantity: 4
- Bolt
- 2.3 Nm
- Quantity: 2
- Bracket
- For the guide strip
- Guide strip
- Removing and installing. Refer to SUN SHADE, REMOVING AND INSTALLING .
- Rear Shelf Rear Section
- Equipment levels
- Engaged in the rear window frame
- Removing and installing. Refer to SUN SHADE, REMOVING AND INSTALLING .
- Trim Panel
- For the rear shelf rear section
- Nut
- 3 Nm
- Quantity: 5
