Condenser, Removing And Installing: Removing

WARNING: This page is about a different car, the 2014 Volkswagen Touareg, 2013 Volkswagen Touareg, 2012 Volkswagen Touareg, and 2011 Volkswagen Touareg. However, it is still accessible from the selected car via links, so may be relevant.

-- Observe safety precautions when working on the high voltage system. Refer to HIGH VOLTAGE SYSTEM SAFETY PRECAUTIONS .

-- Pay attention to safety precautions for working near high voltage components. Refer to SAFETY PRECAUTIONS NEAR HIGH VOLTAGE COMPONENTS .

-- Note the high voltage system danger classification. Refer to HIGH VOLTAGE SYSTEM GENERAL WARNINGS .

Additional work for Hybrid Vehicles

-- Note the high voltage system danger classification. Refer to HIGH VOLTAGE SYSTEM GENERAL WARNINGS .

-- Remove the coolant reservoir and move it to the side. Refer to COOLANT SYSTEM [For engine(s) CATA] .

Vehicles with Refrigerant R134a

-- Drain the refrigerant circuit. Refer to REFRIGERANT CIRCUIT .

Vehicles with Refrigerant R1234yf

-- Drain the refrigerant circuit. Refer to appropriate service information. .

Continuation for All Vehicles

CAUTION:

Danger or frostbite due to refrigerant coming out under pressure.

Frostbite on the skin and other parts of the body is possible.

- Wear safety gloves.

- Wear protective eyewear.

- Extract refrigerant and open the refrigerant circuit immediately.

- If more than 10 minutes elapse after extracting the refrigerant and the refrigerant circuit was not opened, extract the refrigerant again. Evaporation can cause pressure to develop in the refrigerant circuit.

-- For all the following work, close the open lines and connections with clean plugs from the :VAS6122 .

-- Disassemble the radiator module. Refer to appropriate service information. .

Fig 1: Exploded View Of Refrigerant Recycling/Recovery Unit

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Clip
O-ring
- Always replace
- 23.8 mm; 2.4 mm
O-ring
- Always replace
- 9.5 mm; 2.5 mm
Bolts
- 12 ± 1.5 Nm
- Refrigerant Line
Condenser
