Defroster Door Motor -V107-, Removing And Installing: Removing
WARNING: This page is about a different car, the 2014 Volkswagen Touareg, 2013 Volkswagen Touareg, 2012 Volkswagen Touareg, and 2011 Volkswagen Touareg. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the instrument panel. Refer to Instrument Panel .
-- Remove the vehicle electrical system control module with the bracket. .
-- Disconnect the connector from the Defroster Door Motor -V107- -A-.
-- Remove screws -1- and remove the Defroster Door Motor -V107- -A- from the heater and A/C unit.
