Lock Carrier Cover, Removing And Installing: Installing
WARNING: This page is about a different car, the 2014 Volkswagen Touareg, 2013 Volkswagen Touareg, 2012 Volkswagen Touareg, and 2011 Volkswagen Touareg. However, it is still accessible from the selected car via links, so may be relevant.
NOTE:
Before installation, inspect the retaining clips for damage and replace if necessary.
-- Position the lock carrier cover -1- at the outer ends via the centering pins in the corresponding body mounts.
-- Bend the rear lid seal piping and pull it over the edge of the lock carrier cover.
-- Engage the lock carrier cover into the body by pushing in the area of the clips -arrows-.
CAUTION:
To prevent damage, never hit the lock carrier cover during installation!
