Special Tools

WARNING: This page is about a different car, the 2014 Volkswagen Touareg, 2013 Volkswagen Touareg, 2012 Volkswagen Touareg, and 2011 Volkswagen Touareg. However, it is still accessible from the selected car via links, so may be relevant.

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Special tools and workshop equipment required

Tensioner Hooks (2 pc.):VW552
Engine Support Bridge - Spindle: 10-222A/11
Torque Wrench 1331 5-50Nm:VAG1331
Torque Wrench 1332 40-200Nm:VAG1332
Engine and Gearbox Jack:VAS6931
14 mm Bits:T10099/1

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Special tools and workshop equipment required

Press Piece - Multiple Use:VW412
Press Piece - Bushing - 50mm Diameter:VW432
Support Channels:VW 457
Seal Installer - Flywheel Oil Seal Kit - Seal Installer: 2003/3
Subframe Bushing Tool Kit:3301
Sealing Grease:G 052 128 A1

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

Special tools and workshop equipment required

Locking Pin Driver:30-505
Bearing Installer - Needle Bearing:30-506B
-1- - Puller - Kukko Internal - 36-46mm:21/6
-4- - Puller - Kukko Counterstay:22/2

Special tools and workshop equipment required

Puller - Unit Injector:T10055

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Seal Installer - Flange Shaft Oil Seal RH:T10181

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Seal Installer - Flange Shaft:T10256

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Seal Installer - Flange Shaft:T10259

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Seal Installer - Flange Shaft:T10260

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Seal Installer - Shaft Seal:T10431

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Seal Installer - Shaft Seal - Thrust Piece:T10431/1
Seal Installer - Shaft Seal:T10432

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Seal Installer - Shaft Seal - Thrust Piece:T10432/1
Seal Installer - Flange Shaft RH:T10433

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Seal Installer - Flange Shaft LH:T10434

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Seal Installer - Front Final Drive Flange:T10436 for final drive 0BM

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Thrust Piece - Center Bearing:T10529

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Slide Hammer Set:VW771

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
-3- Puller - Kukko Separating Tool - Diameter 25-155mm:15/3

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
-3- - Kukko Separating Tool:17-2

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Centering/Press Pin:12-551

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Driveshaft Alignment Fixture:3139

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Subframe Bushing Tool Kit:3301

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Thrust Piece:3456

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.
Seal Installer - Front Final Drive Input Shaft:T10430
Seal Installer - Front Final Drive Input Shaft - Thrust Piece:T10430/1
Slide Hammer Set - Hook:VW771/37
Press Piece - Multiple Use:30-14
Final Drive Bushing Assembly Tool Kit:T10435
Hydraulic Press - Ball Joint Assembly Tools:T10254
Pneumatic/Hydraulic Foot Pump:VAS6179
Hydraulic Press:VAS6178
600 mm extractor lever (for example, Hazet 652-24)
