Overview - Hood
WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2018 Audi S6, 2018 Audi A6 Quattro, 2018 Audi A6, 2017 Audi S6, and 2017 Audi A6 Quattro. However, it is still accessible from the selected car via links, so may be relevant.
- Cover for the Right Rear Lid Hinge
- Clipped onto the side
- Hood
- A second technician is needed to support and hold the hood during removal and installation.
- Removing
-- Remove the gas-filled strut from the hood. Refer to GAS-FILLED STRUT, REMOVING AND INSTALLING .
-- Remove the nuts -4- from the upper hood hinge.
-- Remove the front lid.
- Install in reverse order of removal.NOTE:
Perform a closing test. The hood must engage completely in the latches from a balanced position.
- Adjusting
-- Center the hood between the fenders.
-- Adjust the height of the hood over the lower section of the latch.
-- Adjust the gap between the hood and the fenders using the stop buffers.
- Cover for the Left Rear Lid Hinge
- Clipped onto the side
- Bolts
- 21 Nm
- Lid Hinge
- For removal and installation, the hood must be removed or supported securely.
- Removing
-- Remove the gas-filled strut. Refer to GAS-FILLED STRUT, REMOVING AND INSTALLING .
-- Remove the bolts -2- and nuts -4-.
- Install in reverse order of removal.
- Gas-Filled Strut
- Removing and installing. Refer to GAS-FILLED STRUT, REMOVING AND INSTALLING .
- Gas-filled strut tube is installed on the lid side.
- Ball Stud
- 10 Nm
- Nut
- 8 Nm
- Hook
- Removing and Installing. Refer to HOOD HOOK, REMOVING AND INSTALLING .
- Nut
- 8 Nm
- Striker
- Removing and Installing. Refer to STRIKER, REMOVING AND INSTALLING .
- Hook
- Removing and Installing. Refer to LOCK CARRIER HOOK, REMOVING AND INSTALLING .
