Overview - Hood Latch
WARNING: This page does not describe the selected car, but rather 13 other vehicles, including the 2017 Audi SQ5, 2017 Audi Q5, 2016 Audi SQ5, 2016 Audi Q5, and 2015 Audi SQ5. However, it is still accessible from the selected car via links, so may be relevant.
- Hood Latch
- Loosen the upper bumper cover and push it aside.
- Disconnect the lid lock cable at the coupling.
- Disconnect the connector.
- Remove the bolts -1 and 2-.NOTE:
To adjust the hood height, move the hood lock up or down as required.
- Lock Carrier
- Bolt
- 15 Nm
- Clamp
- Install the cable and electric wire into the tab on the lock carrier and close the clip.
- Lid Lock Wire
- Cable Tie
