Overview - Wheel Bearing Housing, Wheel Bearing Unit And Coil Spring Shock Absorber, Vehicles With Front Wheel Drive

WARNING: This page does not describe the selected car, but rather 13 other vehicles, including the 2017 Audi SQ5, 2017 Audi Q5, 2016 Audi SQ5, 2016 Audi Q5, and 2015 Audi SQ5. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Overview Of Front Suspension (Vehicles With Front Wheel Drive)

Courtesy of AUDI OF AMERICA, LLC

Protective cap
Nut
- 35 Nm
- Always replace if removed
Bolt
- 50 Nm +45°
- Always replace if removed
Upper Shock Absorber Mount
- Installed position, refer to UPPER SHOCK ABSORBER MOUNT INSTALLATION POSITION
Stop Buffer
Protective Sleeve
Shock Absorber
- Removing and installing, refer to WHEEL BEARING UNIT, REMOVING AND INSTALLING, FWD VEHICLES .
Bolt
- 150 Nm +180°
- Always replace if removed
- Must be tightened in the curb weight position, refer to WHEEL BEARING IN CURB WEIGHT, LIFTING VEHICLES WITH COIL SPRING .
Washer
- serves as corrosion protection
- Always use
Front seal
Wheel bearing unit
CAUTION:
- Avoid contaminating with dirt and damaging the seal when setting down/storing, refer to Fig 2.
- Wheel bearing unit, removing and installing, refer to WHEEL BEARING UNIT, REMOVING AND INSTALLING, FWD VEHICLES .
Bolt
- 200 Nm +180°
- Always replace if removed
Protective cap
- Remove with Puller - Grease Cap VW637/2
- Always replace if removed
Bolt
- Tightening specification, refer to Mechanical Components .
Brake Rotor
Bolt
- Tightening specification, refer to Mechanical Components .
Brake shield
Bolt
- 90 Nm +90°
- Always replace if removed
- Must be tightened in the curb weight position, refer to WHEEL BEARING IN CURB WEIGHT, LIFTING VEHICLES WITH COIL SPRING .
Tie rod
- There are versions made of aluminum and steel.
- A mixed installation is not permitted
Nut
- Always replace if removed
  CAUTION:
  - Do not tighten the threaded connection using the nut.
  NOTE:
  Axle alignment is necessary if the nut is loosened.
Bonded Rubber Bushing
- Replacing, refer to WHEEL BEARING HOUSING BONDED RUBBER BUSHING, REMOVING AND INSTALLING, FWD VEHICLES .
Wheel Bearing Housing
- Removing and installing, refer to WHEEL BEARING HOUSING, REMOVING AND INSTALLING, FWD VEHICLES .
Spacer tube
- Always replace if removed
Lower transverse link
Bolt
- 120 Nm +360°
- Always replace if removed
- Must be tightened in the curb weight position, refer to WHEEL BEARING IN CURB WEIGHT, LIFTING VEHICLES WITH COIL SPRING .
  NOTE:
  Axle alignment is necessary if the bolt is removed.
Upper Transverse Link
Shim
Nut
- 95 Nm
- Always replace if removed
- Must be tightened in the curb weight position, refer to WHEEL BEARING IN CURB WEIGHT, LIFTING VEHICLES WITH COIL SPRING .
Bolt
Bolt
- Tightening specification, refer to Mechanical Components .
Rear Wheel Speed Sensor

Fig 2: Always Set Wheel Bearing Down On Wheel Hub -2- (Wheel Bearing -1- Facing Up)

Courtesy of AUDI OF AMERICA, LLC

The wheel bearing -1- must always face up.
Always set the wheel bearing down on the wheel hub -2-.
