Left/Right Front Turn Signal Bulb -M5- / -M7-, Removing And Installing, Hid Headlamps From My 2013: Removing

WARNING: This page does not describe the selected car, but rather 13 other vehicles, including the 2017 Audi SQ5, 2017 Audi Q5, 2016 Audi SQ5, 2016 Audi Q5, and 2015 Audi SQ5. However, it is still accessible from the selected car via links, so may be relevant.

-- Turn the light switch to position "0".

-- Turn off the ignition and all electrical consumers and remove the ignition key.

-- Do not touch the flasher.

-- On the right: remove the air filter housing, refer to AIR FILTER HOUSING, REMOVING AND INSTALLING .

Fig 1: Headlight Access Cover (HID Headlamps From MY 2013)

Courtesy of AUDI OF AMERICA, LLC

-- Release the retaining tabs -4 and 5-.

-- Remove the housing cover -3-.

-- Press down on release -2- to disconnect the connector -1-.

-- Disengage bulb socket -1- counter-clockwise -arrow-.

Fig 2: Removing Bulb Socket From Housing

Courtesy of AUDI OF AMERICA, LLC

-- Pull the bulb socket out of the housing.

-- Press the release -arrow- and remove the connector -2- from the socket -1- with the bulb.

Fig 3: Identifying Bulb & Connector

Courtesy of AUDI OF AMERICA, LLC
