Lower Bracket For The Rear Side Airbag, Removing And Installing: Removing

WARNING: This page does not describe the selected car, but rather 13 other vehicles, including the 2017 Audi SQ5, 2017 Audi Q5, 2016 Audi SQ5, 2016 Audi Q5, and 2015 Audi SQ5. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Locating Lower Bracket Nuts For Rear Side Airbag

Courtesy of AUDI OF AMERICA, LLC

-- Remove the rear sill trim. Refer to SILL PANEL, REMOVING AND INSTALLING, REAR SILL PANEL .

-- Remove the nuts -1- and then remove the bracket -2-.
