Ribbed Belt Tensioning Damper, Removing and Installing, Vehicles with Electro-Mechanical Power Steering: Removing
WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 2016 Audi A4 Quattro, 2016 Audi A4, 2015 Audi A4 Quattro, 2014 Audi A4 Quattro, and 2013 Audi A4. However, it is still accessible from the selected car via links, so may be relevant.
- Remove the ribbed belt from the tensioner. Refer to Ribbed Belt, Removing and Installing, Vehicles with Electro-Mechanical Power Steering .
- Remove the bolts -arrows- and remove the ribbed belt tensioner -1- from the sub-assembly bracket.
