Side trim, inboard side, assembly overview

WARNING: This page does not describe the selected car, but rather 14 other vehicles, including the 2009 Audi S4, 2009 Audi A4, 2008 Audi S4, 2008 Audi RS 4, and 2008 Audi A4. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Side Trim, Inboard Side, Assembly Overview

Courtesy of VOLKSWAGEN UNITED STATES, INC.

1 - Backrest

2 - Bolts (4x)

3 - Rear side trim, outboard side

4 - Front side trim, outboard side

5 - Connector (3x)

6 - Side trim, inboard side

Removing

Remove seat → Seat, assembly overview .
Disengage rubber strap of backrest cover - 8 -.
Remove bolts - 7 - (2x).
Remove side trim - 6 - upward.

7 - Bolts (2x)

8 - Rubber strap of backrest cover
