Side Window Mounting Piece, Removing And Installing: Removing

WARNING: This page does not describe the selected car, but rather 19 other vehicles, including the 2017 Audi S5, 2017 Audi A5 Quattro, 2016 Audi S5, 2016 Audi A5 Quattro, and 2015 Audi S5. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Side Window Mount

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- "Open" the rear side window.

-- Remove the inner window shaft strip. Refer to INNER WINDOW SHAFT STRIP, REMOVING AND INSTALLING .

-- Remove the seat belt positioning motor. Refer to SEAT BELTS , Driver and Front Passenger Seat Belt Positioning Motors -V413- / -V414-, Removing and Installing.

-- Remove the foam piece -1-.

-- Remove the bolts -arrows-.

-- Remove the side window mount -2- upward.
