Power Convertible Top Valve 1, 2, And 3 -N272- / -N341- / -N342-, Removing And Installing: Removing

WARNING: This page does not describe the selected car, but rather 19 other vehicles, including the 2017 Audi S5, 2017 Audi A5 Quattro, 2016 Audi S5, 2016 Audi A5 Quattro, and 2015 Audi S5. However, it is still accessible from the selected car via links, so may be relevant.

-- Remove the hydraulic pump. Refer to HYDRAULIC UNIT (HYDRAULIC PUMP), REMOVING AND INSTALLING .

CAUTION:

Risk of damage.

Carefully release the connector from the valve with a small screwdriver. Do not break the locking mechanism.

-- Disconnect the connector -1-.

Fig 1: Disconnecting Connector

Courtesy of VOLKSWAGEN GROUP OF AMERICA, INC.

-- Remove the bolt -3-.

-- Remove it by lightly turning the valve -2- out of the valve block -4-.
