Left/Right Back-Up Lamp Bulb 2 -M76- / -M77-, Removing And Installing: Installing
WARNING: This page does not describe the selected car, but rather 19 other vehicles, including the 2017 Audi S5, 2017 Audi A5 Quattro, 2016 Audi S5, 2016 Audi A5 Quattro, and 2015 Audi S5. However, it is still accessible from the selected car via links, so may be relevant.
- Tightening specification. Refer to OVERVIEW - REAR LID TAIL LAMPS .
Install In Reverse Order Of Removal. Note The Following:
-- Insert the new bulb in the socket without touching the bulb with bare hands.
-- Slide the large clamping bracket -3- onto the inner tail lamp threaded pins. The centering pins -2- and -6- must engage in the mounts.
-- Tighten the nuts -1-.
NOTE:
When tightening the nuts, the clamping bracket wedges itself onto the rear lid -arrows-.
Ignore items -4 and 5-.
