Attachments, Removing And Installing, AUDI RS5: Installing
WARNING: This page does not describe the selected car, but rather 19 other vehicles, including the 2017 Audi S5, 2017 Audi A5 Quattro, 2016 Audi S5, 2016 Audi A5 Quattro, and 2015 Audi S5. However, it is still accessible from the selected car via links, so may be relevant.
- Tightening specifications. Refer to OVERVIEW - BUMPER COVER, AUDI RS5 .
Install in reverse order of removal. Note the following:
-- The diffuser trim must engage completely.
Tail Pipe Trim
Removing
-- Remove the rear bumper cover. Refer to BUMPER COVER, REMOVING AND INSTALLING .
-- Remove the bolts -arrows-.
-- Remove the tail pipe trim -1- inward from the bumper cover.
Installing
- Tightening specifications. Refer to OVERVIEW - BUMPER COVER, EXCEPT AUDI RS5 .
Install in reverse order of removal. Note the following:
-- Check the trim distance for the tail pipe -2- on the bumper cover -1- :
- Dimension -x- = uniform gap.
-- Install the rear bumper cover. Refer to BUMPER COVER, REMOVING AND INSTALLING .
Mount for the Tail Pipe Trim
Install in reverse order of removal. Note the following:
-- Install the tail pipe trim. Refer to Installing .
