Lines And Hoses Overview [CCBA, CGXC]: Notes
WARNING: This page does not describe the selected car, but rather 19 other vehicles, including the 2017 Audi S5, 2017 Audi A5 Quattro, 2016 Audi S5, 2016 Audi A5 Quattro, and 2015 Audi S5. However, it is still accessible from the selected car via links, so may be relevant.
Line and hose securing elements, assembly overview
- Reservoir bracket to body, refer to Figure.
- Reservoir in bracket, refer to Figure.
- Bolt inside the bracket, refer to Figure.
- Hydraulic oil cooler to condenser, refer to Figure.
- Power steering pump inside the bracket with power steering pump control valve -(V119)- POWER STEERING PUMP, VEHICLES WITH DYNAMIC STEERING [CCBA, CGXC] or without the power steering pump control valve -(V119)- POWER STEERING PUMP, VEHICLES WITH DYNAMIC STEERING [CCBA, CGXC] .
- Pressurized line to crossbrace, refer to Figure.
- Pressure line connection installation location, refer to Figure.
- Pressurized line to the engine mount refer to Figure.
- Return line to the subframe, refer to Figure.
- Return line bracket to the longitudinal member, refer to Figure or Figure.
