Secondary Air Injection Pump -V101-, Removing And Installing, AUDI RS5 Convertible: Removing
WARNING: This page is about a different car, the 2015 Audi RS 5, 2014 Audi RS 5, and 2013 Audi RS 5. However, it is still accessible from the selected car via links, so may be relevant.
-- Remove the front bumper cover. Refer to Front Bumper .
-- Disconnect the connectors -1- and free them up.
-- Press the release buttons and remove the crankcase ventilation hoses -3 and 4-.
-- Remove the nuts -arrows- and remove the Secondary Air Injection Pump Motor -V101- from the bonded rubber bushing -2-.
