Engine And Transmission, Separating [XXXX]: Procedure

WARNING: This page is about a different car, the 2016 Audi A3 and 2015 Audi A3. However, it is still accessible from the selected car via links, so may be relevant.

Courtesy of AUDI OF AMERICA, LLC

Engine/transmission assembly removed and mounted on :T10497 .

-- Removing starter. Refer to STARTER .

-- Remove bolts -arrows- and remove the transmission support.

Courtesy of AUDI OF AMERICA, LLC

-- Install :T40013 on the transmission and close locking device.

Courtesy of AUDI OF AMERICA, LLC

-- Engage the :VAS6100 with :10-222A/2 on the transmission lift hook.

-- Remove the bolts -1, 2, 5, 6, 7 and 8- connecting the transmission to the engine.

Courtesy of AUDI OF AMERICA, LLC

-- Remove the transmission from the engine, pay attention to the intermediate plate while doing so.
