Oil Separator
WARNING: This page is about a different car, the 2018 Audi Q3 Quattro, 2018 Audi Q3, 2017 Audi Q3 Quattro, and 2017 Audi Q3. However, it is still accessible from the selected car via links, so may be relevant.
Oil Separator on Cylinder Head Cover, Version 1
The oil separator is visible after the engine cover is removed. Refer to ENGINE COVER, REMOVING AND INSTALLING .
Oil Separator on Cylinder Head Cover, Version 2
The oil separator is visible after the cylinder "3 and 4" ignition coils are removed. Refer to IGNITION COILS WITH POWER OUTPUT STAGES, REMOVING AND INSTALLING .
Oil Separator on Cylinder Block, Version 1
- 8 connection points
Oil Separator on Cylinder Block, Version 2:
- 9 connection points
