Rear Window Breakage Sensor, Alarm Horn, Left Luggage Compartment Lamp, Right Luggage Compartment Lamp
G304 Rear window breakage sensor
H12 Alarm horn
J519 Vehicle electrical system control module
T2iv 2-pin connector, black
T2iw 2-pin connector, black
T2kg 2-pin connector, black
T3ci 3-pin connector, black
T17 17-pin connector, Rear lid coupling point
T52a 52-pin connector, black
T52b 52-pin connector, naturally cloudy
W18 Left luggage compartment lamp
W35 Right luggage compartment lamp
(51) Ground connection in luggage compartment, right
(61) Ground connection on left C-pillar
(85) Ground connection 1 (in engine compartment wiring harness)
(382) Ground connection 17 (in main wiring harness)
(383) Ground connection 18 (in main wiring harness)
(655) Ground connection on left headlamp
(B470) Connection 6 (in main wiring harness)
(B528) LIN bus connection 1 (in main wiring harness)
* For vehicles with anti-theft alarm system
*2 Depending on equipment
