System Diagram [08/2013 - ]

WARNING: This page is about a different car, the 2014 Lexus ES 300h. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Parking Assist Monitor System Wiring Diagram (1 Of 2)
GTY415372Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Parking Assist Monitor System Wiring Diagram (2 Of 2)
GTY401834Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
COMMUNICATION TABLE

Sender Receiver Signal Line
Multi-media Module Receiver Assembly Multi-display Assembly Video signal Digital
Spiral Cable with Sensor Sub-assembly Multi-media Module Receiver Assembly Steering angle signal CAN Communication Line
Power Management Control ECU Multi-media Module Receiver Assembly Shift position signal CAN Communication Line
Brake Booster with Master Cylinder Assembly (Skid Control ECU) Multi-media Module Receiver Assembly Vehicle speed signal CAN Communication Line
Luggage Closer Motor Assembly*1 Main Body ECU (Multiplex Network Body ECU) Luggage courtesy switch signal CAN Communication Line
Main Body ECU (Multiplex Network Body ECU) Multi-media Module Receiver Assembly
  • Vehicle information signal
  • Luggage courtesy switch signal
 CAN Communication Line
